FRAME
Alloy Frame / Virtual 4 link kinematic VLK, 27.5" and 29" compatible / geo adj. / Boost 148x12mm, 140mm travel / Bosch Gen4 / Integr. removable Battery, Tapered Headtube E2, Central Kickstand Mount, Range Booster Ready
TRAVEL
Front: 140mm / Rear: 140mm
FORK
Marzocchi Z2 Air / eMTB+, Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel
REAR SHOCK
X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj, 3 modes: Lockout-Traction Control-Descend, Reb. Adj, Travel 140-90-Lockout / 185x50mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 modes
DRIVE UNIT
Bosch Performance CX, EU: 25kmh / INT: 20mph
BATTERY
PowerTube 625Wh
DISPLAY
Bosch Purion
CHARGER
4A Charger
REAR DERAILLEUR
SRAM NX Eagle / 12 Speed
SHIFTERS
SRAM SX Eagle Single Click
CRANKSET
FSA CK-320 / 165mm / 34T
CHAINRING
SRAM Eagle 34T DM / Steel
CHAIN
SRAM SX Eagle
CASSETTE
SRAM PG1210 / 11-50 T
BRAKES
SRAM DB8 4 Piston Disc
ROTOR
Centerline CL Rotors 200mm F&R
HANDLEBAR
Syncros Hixon 2.0 Rise / Alloy 6061D.B, 20mm rise / 8° / 760mm, Syncros Comfort lock-on grips
H'STEM
Syncros FL2.0 / 6061 Alloy, L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L size 150mm / XL size 170mm
SEAT
Syncros Capilano
HEADSET
Syncros ER2.0 Press Fit E2 / Tapered 1.5"-1 1/8", OD 52/62mm / ID 44/56mm
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula CL-148S / Boost 148x12mm
SPOKES
Stainless Black
RIM
SSyncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
FRONT TIRE
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual
REAR TIRE
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual
LIGHTS
Bosch Light Cable pre-installed F&R
APPROX WEIGHTS IN
KG24.3 (with tubes)
APPROX WEIGHTS IN
LBS53.57 (with tubes)
MAX. SYSTEM WEIGHT
128kg, The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
