FRAME
Lumen eRIDE Carbon HMX, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
TRAVEL
Front: 130mm / Rear: 130mm
FORK
FOX 34 Float Rhythm Air Grip, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 130mm travel
REAR SHOCK
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 130-90-Lockout / T165X45mm
REMOTE SYSTEM
SCOTT TwinLoc Suspension System, 3 modes front and rear / integ. Grip clamp
DRIVE UNIT
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
BATTERY
TQ Internal 360Wh
DISPLAY
TQ HPR, Bluetooth / ANT+ / Dedicated Smartphone app
CHARGER
TQ 100-240V-4A
REAR DERAILLEUR
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
SHIFTERS
Shimano Deore SL-M6100-IR / Rapidfire Plus, Ispec EV clamp
CRANKSET
FSA Alloy crankset / 175mm / 34T
CHAINGUIDE
e*thirteen / e*spec Slider
CHAINRING
Scott custom spider / FSA 12Speed 34T chainring
CHAIN
Shimano CN-M6100
CASSETTE
Shimano CS-M6100 / 10-51 T
BRAKES
Shimano Deore M6120 4 Piston Disc
ROTOR
Front: SM-RT64 CL 180mm / Rear: RT-EM600 CL 180mm
HANDLEBAR Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise / back sweep 8° / 760mm, Syncros Performance XC lock-on grips
H'STEM
Syncros DC 2.0, Syncros Cable Integration System, 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.0, 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm
SEAT
Syncros Tofino 1.5 Regular, Titanium rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula CL-148M / 12x148mm / Micro Spline, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
SPOKES
Stainless Black 15G / 1.8mm
RIMS
Syncros X-30SE / 32H / 30mmm Tubeless ready
FRONT TIRE
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft
REAR TIRE
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip
APPROX WEIGHTS IN KG
17.6 (Tubeless setup)
APPROX WEIGHTS IN LBS
38.8 (Tubeless setup)
