FRAME
Carbon Main Frame / Alloy SST-CST-Link, Virtual 4 link kinematic VLK, 29x2.6 / Boost 148x12mm UDH, 160mm travel / Bosch Gen4 / Integr. removable Battery, 1.8" Headtube, Central Kickstand Mount, Integr. Cable
TRAVEL
Front: 160mm / Rear: 160mm
FORK
FOX 38 Perf. Elite Air / eMTB+ / FIT4, 3-Modes with low Speed adj. / QR Axle 15x110mm axle, 44mm offset / tapered steerer / Reb. Adj. / Lockout / 160mm travel
REAR SHOCK
FOX NUDE T eRIDE EVOL / Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, custom large air volume / DPS / Reb. Adj., Travel 160-115-Lockout / 205X60mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 modes
DRIVE UNIT
Bosch Performance CX, EU: 25kmh / INT: 20mph
BATTERY
PowerTube 750Wh
DISPLAY
Bosch LED Remote & Kiox 300
CHARGER
4A Charger
REAR DERAILLEUR
Shimano XT / 12 Speed
SHIFTERS
Shimano SL-M8100
CRANKSET
FSA CK-745 165mm / 34T
CHAINGUIDE
FSA W0138+WB499 / 34T / Steel
CHAINRING
FSA WB604 / 34T / DM / Steel
CHAIN
Shimano CN-M8100
CASSETTE
Shimano CS-M8100 / 10-51 T
BRAKES
Shimano XT / BR-M8120 4 Piston
ROTOR
Front: RT-MT800 CL 203mm / Rear: RT-EM800 CL 203mm
HANDLEBAR
Syncros Hixon 1.5 / Alloy 7050D.B., 12mm rise / 9° / 780mm, Syncros Endurance lock-on grips
H'STEM
Syncros AM1.5 / 7050 Alloy, 31.8mm / 4° / 1 1/8"
SEATPOST
FOX Transfer Dropper Post, 31.6mm / S size 125mm / M size 150mm / L size 175mm / XL size 200mm
SEAT
Syncros Tofino 1.5 Regular, Titanium rails
HEADSET
Acros / 1.8", ZS66 OD74 / integr. Cable
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula ECT-1481 / Boost 148x12mm
SPOKES
Stainless Black
RIMS
Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
FRONT TIRE
Maxxis Dissector 29x2.6", 120TPI Foldable Bead, EXO+ / TR Tubeless ready, 3C Maxx Terra
REAR TIRE
Maxxis Dissector 29x2.6", 120TPI Foldable Bead, EXO+ / TR Tubeless ready, 3C Maxx Terra
LIGHTS
Syncros integrated rear fender light, Front Light Cable pre-installed
EXTRAS
Syncros Fork Fender
APPROX WEIGHTS IN KG
24.6 (with tubes)
APPROX WEIGHTS IN LBS
54.23 (with tubes)
MAX. SYSTEM WEIGHT
128kg
